Latest updates
2024
Addition to the lab for 3D printed housing prototypes
December 2019
New equipment for pre compliance testing of conducted emission.
February 2018
New equipment for bench top pre compliance immunity testing up to 30V/m
VNA for antenna testing and optimization up to 3GHz
December 2015
New homepage
August 2014
New low cost board for remote supervision via GSM modem.
Full specification here
April 2011
3rd generation industrial control with GPRS and/or Ethernet remote connection used for off-grid telecom sites with hybrid (Wind, Solar, Diesel) power supply
– ARM Cortex-M3 150 DMIPS
– GPRS modem
– 10/100 Mbit Ethernet
– SD card for data logging
– 128 x 64 pixel OLED 1,54″
– 3 LED + 4 button membrane keypad connector
– +24V or -48V supply
– 2 voltage inputs 0-60V
– 4 temperature inputs
– 2 4-20 mA inputs
– 4 current sensor inputs (2 shunt + 2 hall sensor)
– 3 digital potential free inputs
– 9 solid state relay outputs 60V@0.1A
– 3 relay output 60V/1A
– Size: 235 x 93 mm
– Software: Battery charge/discharge management, Diesel control, ATS control, temperature control, XML-RPC server interface
April 2011
October 2010
2010-02-12
Small Industrial Controller with OLED:
– ARM Cortex-M3 36 MHz, 128 kB Flash, 16 kB RAM, 2 kB EEPROM
– 128 x 64 pixel white OLED 0.96″
– Single 24VDC supply
– 8 high side outputs 24V@2.5A, one with current measurement
– 8 high side outputs 24V@0.6A to 1.2A current limited
– 2 water level sensing inputs
– 2 digital inputs for potential free switches
– Buzzer
– Input for two matrix keypads 2×3 and 4×3 switches
– Micro SD card reader
– Output for driving 4×3 LED matrix, i e status indication for 4×3 keypad
– NTC input
– Size 110 x 41 mm
– Price: 35€/pcs for 1k annual volume incl OLED
2009-01-15
We have invested in EMC measurement equipment and are now able to analyse radiated emission at our own facilities.
